Makita VR004GZ 40V Cordless Concrete Vibrator Shaft / Hose (XGT) [Bare]
2.4 m (7.9 ft) 38 mm (1-1/2″) 15,500 VPM Cordless Concrete Vibrator 40Vmax XGT™ Li-Ion/PDC01/PDC1200 [BARE TOOL]
- 40Vmax XGT Cordless 38 mm (1-1/2″) Concrete Vibrator
- Compatible with large diameter shafts
- VR001G series supports a larger vibration part diameter than the current model and transmits vibration to a wider range to improve compaction efficiency thanks to 40Vmax XGT Li-Ion battery and BL motor
- Flexible shafts from ø28 to ø38 are suitable for a wide range of jobsites
- Two power mode selection (normal/power) allows to use the machine for a wide range of jobsites:
- Power mode: For a wide range of concrete compaction, such as of soil floors, pillars, and mat foundations
- Normal mode: Ideal for delicate works, such as step finishing or closure of temporary construction openings, where concrete is required not to flow out of the mold
- With Flexible shaft ø38-1.2m or ø38-2.4m
- Constant speed control allows for stable compaction work
- Switch cover protects switch trigger and lock-on button from being blocked by adhered and hardened material such as concrete
- Various Battery covers are available for all recommended or compatible batteries
- The supplied Battery cover is compatible with BL4020/BL4025/BL4040
- The following Battery covers are also available as an option:
- ∙ Battery case L set for BL4050F/BL4080F
- ∙ Battery case H set for PDC01/PDC1200
- Extreme Protection Technology (XPT) is engineered for improved dust and water resistance for operation in harsh conditions
- Shoulder strap (sold separately) can be attached
- Ergonomically designed handle fits your hand well
- Lock-on switch reduces hand fatigue in long continuous operation
- Trigger lock minimizes accidental start-up during transportation
- Battery capacity warning lamp indicates ideal time to recharge battery
- Anti-restart function engineered to minimize motor start up when battery is inserted with switch locked on
- Flexible shaft thread size
- Flexible core shaft: M6 x 1.0
- Coupling of Outer casing: M36 x 1.5
- Battery protection circuit protects against overloading, over-discharging and over-heating
- Battery and charger are sold separately.
Specifications:
MAX OUTPUT | w/ PDC1200: 550 W |
VIBRATOR DIAMETER | 38 mm |
FLEXIBLE SHAFT LENGTH | 1,2, 2,4 m |
VIBRATIONS PER MINUTE (VPM)
|
Power mode: 15.500 |
Normal mode: 12.000 | |
WORK AMOUNT ON A FULL BATTERY CHARGE
|
w/ 28mm-0.8m shaft, w/ BL4040, Power mode: 45 min |
w/ 28mm-0.8m shaft, w/ BL4040, Normal mode: 60 min | |
VIBRATION LEVEL | 4,9 m/s² |
VIBRATION K FACTOR | 1,5 m/s² |
SOUND PRESSURE LEVEL | 80 dB(A) |
NOISE K FACTOR | 3 dB(A) |
DIMENSIONS (L X W X H) | w/o Flexible shaft, w/ BL4020/BL4025/BL4040: 282 x 112 x 258 mm |
w/o Flexible shaft, w/ BL4050F/BL4080F and Battery case L set: 296 x 112 x 299 mm | |
NET WEIGHT | 4.8 – 7.8 kg |
Inclusions:
Wrench 8 781213-9(1)
Lifetime Service Warranty
